• Burkert Solenoid Valve 021396, 3 port(s) , NO/NC, 230 V ac, 1/4inRS Stock No.:440-767หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:021396
1 1

Burkert Solenoid Valve 021396, 3 port(s) , NO/NC, 230 V ac, 1/4inRS Stock No.:440-767หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:021396

Burkert Solenoid Valve 021396, 3 port(s) , NO/NC, 230 V ac, 1/4inRS Stock No.:440-767หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:021396

13,606.00 ฿
17,008.00 ฿ 13,606.00 ฿
ลดราคา ขายหมดแล้ว

Burkert

รายละเอียด Burkert Solenoid Valve 021396, 3 port(s) , NO/NC, 230 V ac, 1/4inRS Stock No.:440-767หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:021396

Stainless steel bodied, 3-way, Type 330

Solenoid valves with pivoted armatures which provide high pressure operation with aggressive gases and fluids.

BSP parallel ports compatible with RS stainless compression fittings
IP65 rated 3-pin DIN connector can be positioned through 360° in 90° increments
Zero head pressure capability
Lockable manual override
Fluid temperature range -30 to +90°C
May be mounted in any position
Power consumption 5VA/8W (Constant), 30VA (a.c. inrush)

คุณสมบัติ Value
Supply Voltage 230 V ac
Number of Ports 3
Connection Size 1/4in
Connection 1/4 in G Female
Operation Direct
Default Valve Position NO/NC
Suitable Applications Aggressive Gas, Aggressive Liquid
Type 3/2
Orifice Diameter 3mm
Body Material Stainless Steel
Series 0330
Maximum Working Pressure 6 bar
Operating Temperature Range -30 → +55 °C
Connection Gender Female
Maximum Operating Temperature +55°C
Thread Standard or Connection Type G
Minimum Operating Temperature -30°C
Flow Factor Kv 0.23m³/h
