| Part | Material | Size |
|---|---|---|
| Body | Bronze BS EN 1982 CC491K | All |
| Cap | Bronze BS EN 1982 CC491K | All |
| Disc | Brass BS EN 12164 CW614N | 3/8 - 1 |
| Disc | Bronze BS EN 1982 CC491K | 1 1/4 - 3 |
| Hinge | Bronze BS EN 1982 CC491K | All |
| Hinge Pin | Stainless Steel SS316 | 3/8 - 2 |
| Hinge Pin | Brass BS EN 12164 CW614N | 2 1/2 & 3 |
| Hinge Nut | Brass BS EN 12164 CW614N | All |
| ID Plate | Aluminium | All |
| Drive Pin | Steel - Electro Brassed | All |
| Hinge Pin Plug | Brass BS EN 12164 CW614N | 2 1/2 & 3 |
Dimensions & Weights
| SIZE(mm) | WEIGHT(Kg) | A(mm) | B(mm) | C(mm) |
|---|---|---|---|---|
| 3/8 | 0.19 | 50 | 33 | - |
| 1/2 | 0.32 | 59 | 38 | 8.53 |
| 3/4 | 0.43 | 68 | 42 | 15.55 |
| 1 | 0.61 | 81.5 | 49 | 26.27 |
| 1 1/4 | 1.01 | 93.2 | 56 | 46.49 |
| 1 1/2 | 1.34 | 98.3 | 65 | 64.77 |
| 2 | 2.12 | 110.6 | 76 | 112.24 |
| 2 1/2 | 4.08 | 155.6 | 98 | 164.53 |
| 3 | 5.76 | 190 | 99 | 254.05 |
