| L1 | 311 mm |
| L2 | 287 mm |
Featurde
| Inch-Metric | Metric |
| Accuracy | 0,03 mm |
| ORIGIN (ABS-Zero) | Yes |
| Low voltage alarm | Yes |
| Repeatability | 0.01 mm |
| Max. response speed | Unlimited |
| Data output | Yes |
| Data output | Yes |
| Mass | 0.43 kg |
Description
- You can use this scale unit in adverse environments with water and cutting oil due to it new detection method (electromagnetic induction).
- Specially designed output cables are developed to maintain the water resistant structure.
- You will have no overspeed error since the ABSOLUTE scale does not depend on counting scale graduations.
- Once an absolute zero (origin) point is set, the Digimatic Scale Unit shows the absolute distance from this point when it is powered on, rather than „0.00“.
