Product size
Product details
| Gross weight | 1.36 kg |
| Net weight | 1.35 kg |
| Ambient temperature range [°C] [Max] | 70 °C |
| Ambient temperature range [°C] [Min] | -50 °C |
| Ambient temperature range [°F] [Max] | 158 °F |
| Ambient temperature range [°F] [Min] | -58 °F |
| Ammonia application | Yes |
| Approval | CCC,CE,DNV,EAC,GL,KR,LR, LVD,NKK,PZH,RINA,RMRS,RoHS,RoHS,China TYSK,LLC, CDC, EURO-TYSK,UKCA |
| Contact differential [bar] | 0.1 bar |
| Contact function | SPDT |
| Contact rating | AC15=3 A, 400 V
AC1=10 A, 400 V DC13=12 W, 220 V AC3=4 A, 400 V LR=28 A, 400 V |
| Diff.press.setting range [bar] [Max] | 1.5 bar |
| Diff.press.setting range [bar] [Min] | 0.1 bar |
| Diff.press.setting range [MPa] [Max] | 0.15 MPa |
| Diff.press.setting range [MPa] [Min] | 0.01 MPa |
| Diff.press.setting range [psi] [Max] | 21.8 psi |
| Diff.press.setting range [psi] [Min] | 1.5 psi |
| Electrical conn. Male/Female | Female |
| Electrical connection | Screwed cable entry |
| Electrical connection size | 2xPg 13.5 |
| Electrical connection standard DIN | 40430 |
| Electrical spec. standard | EN 60947-4/-5 |
| EN 60947 electrical properties | Pollution degree: 3
Rated impulse voltage: 4 kV Short circuit prot, fuse: 10A |
| EN 60947 wiring properties | Flex, ferrules: 0.2-1.5 mm2
Flex, no ferrules: 0.2-2.5 mm2 Solid/stranded: 0.2-2.5 mm2 |
| Enclosure rating IP | IP66 |
| Max. test pressure [bar] | Pe 13 bar |
| Max. test pressure [psig] | 188 psig |
| Max. Working Pressure [bar] | 11 bar |
| EAN | 5702428042802 |
| Max. Working Pressure [psig] | 160 psig |
| Operat. range LP side [bar] Pe [Max] | 9 bar |
| Operat. range LP side [bar] Pe [Min] | -1 bar |
| Operat. range LP side [psig]Pe [Max] | 131 psig |
| Operat. range LP side [psig]Pe [Min] | -15 psig |
| Packing format | Multi pack |
| Pressure connection notes | Weld nipple d6.5/D10mm |
| Pressure connection size | 3/8 |
| Pressure connection standard | ISO 228-1 |
| Pressure connection type | G |
| Pressure Male/Female | Male |
| Pressure range [bar] Pe [Max] | 9 bar |
| Pressure range [bar] Pe [Min] | -1 bar |
| Product accessories | Generic accessories
Switches accessories |
| Product description Diff | Pressure Switch |
| Product family name | RT Pressure switch |
| Product group | Switches and thermostats |
| Product name | Differential pressure switch |
| Quantity per packing format | 9 pc |
| REACH Candidate List substances >0.1% | Lead (CAS no. 7439-92-1) |
| Refrigerant | R11,R12,R123,R124,R134a
R22,R404A,R407A,R407C,R407F R407H,R422B,R422D,R438A,R507C,R717 |
| Relay release time [s] | 0 " |
| Reset function | Auto |
| Serviceable | Contact systems |
| Type | RT260A |
| UL approved refrigerants | R11,R12,R123,R124,R134a,R22
R404A,R407A,R407C,R407F,R407H R422B,R422D,R438A,R507C |
